Used 2020 SAIC Hongyan Genlvon 450HP Dump Tipper Truck 8*4
Hongyan Genlvon Truck, 8*4 Truck, Dump Truck, Tipper Truck, Used
Truck
Stable and reliable, pioneer in urban construction, intelligent and
efficient, safe and environmentally friendly
Urban construction waste
- Intelligent driving network, spider cockpit
Spider Intelligent Drive L2+. Spider Zhilian 3.0 blessing,
real-time remote diagnosis of vehicle faults, timely reminders, to
ensure the safety of vehicle operation, and the level of
intelligence has reached the industry-leading level
- Diversified energy mix, economical, environmentally friendly and
efficient
Relying on big data analysis + real scene diagnosis, it can
customize diversified performance for users. National VI power,
pure electric power, hydrogen fuel power and other energy
combinations. 100% coverage of transportation scenarios, more
economical and efficient
The cab, chassis, power chain, electronic appliances and other
whole vehicles have evolved, with new functions, and equipped with
super brakes to provide stronger safety guarantee for complex road
conditions
- Car follow your heart and drive comfortably
The new interior is equipped with air buoyancy seats, anti-slam
automatic sunroof, multi-function steering wheel, coupe-level frame
control, smart home appliances, luxury large flats, etc., making
the driving process full of pleasure
| Basic Information |
| Announcement model: | CQ3316HXVG486LA | Drive form: | 8X4 |
| Wheelbase: | 1800+4800+1400mm | engine: | Shanghai Philippine Red F3GCE611A*L |
| Gearbox: | Fast 12JSD220T | Rear axle ratio: | 5.214 |
| Body length: | 11.735 meters | Body width: | 2.55 meters |
| Body height: | 3.86 meters | Front track: | 2006/2006mm |
| Rear Track: | 1850/1850mm | Vehicle weight: | 15.32 tons |
| Rated load: | 15.55 tons | Total mass: | 31 tons |
| Tonnage class: | Heavy Truck | Approach angle: | 21 degrees |
| Departure angle: | 14 degrees | Origin: | chongqing |
| Market segments: | Urban construction waste, road transport | Overall ratio: | 5.214 |
| Engine parameters |
| engine model: | Shanghai Philippine Red F3GCE611A*L | Engine Brand: | Philippine Red |
| Number of cylinders: | 6 | Fuel type: | diesel fuel |
| Displacement: | 11.12L | Emission Standards: | country five |
| Maximum horsepower: | 450 hp | Maximum output power: | 327kW |
| Max torque: | 2100N m | Maximum torque speed: | 1100-1500rpm |
| Rated speed: | 1900rpm | | |
| Cargo box parameters |
| Cargo Length: | 8.8 meters | Cargo width: | 2.35 meters |
| Cargo height: | 1.5 metres | Cargo box form: | self-unloading |
| Cab parameters |
| Cab: | Jay Lion | | |
| Transmission parameters |
| Gearbox Model: | Fast 12JSD220T | Gearbox brand: | Fast |
| Forward gear: | 12 gears | Number of reverse gears: | 2 |
| Chassis parameters |
| Front axle allowable load: | 6500/6500kg | Rear axle allowable load: | 18000 (two-axis group) kg |
| Speed ratio: | 5.214 | Number of spring pieces: | 3/3/4, 3/3/6, 9/9/12, 10/10/12 |
| tire |
| Tire Specs | 11.00R20 18PR,12.00R20 18PR | Number of tires: | 12 |
