Used 2020 FAW 6*4 Tractor Head Truck Han V 460HP
Used Tractor Head, Used Truck, FAW Truck, FAW Tractor Head, 6*4
Model positioning
Logistics distribution, coal transportation, port transportation,
hazardous chemicals transportation.
Model introduction
It can also be seen from the name that the Hummer V is a model used
to replace the original Hummer. The cab looks no different from the
Dragon V in appearance. The only difference may be that the fenders
are not the same color as the body. In fact, the two use the same
cab, and it is not surprising that there is no difference. Like the
Tian V, it also offers two types of cabs with a high roof and a
flat roof.
Dynamic parameters
Some card friends may have questions: since the cab is the same,
why does Qingdao Jiefang still launch two models? There are
definitely differences. In terms of power configuration, the
maximum horsepower of the Han V is 460 horsepower, and the minimum
is 280 horsepower. This horsepower coverage is suitable for
short-distance and lightweight needs, and the positioning is the
same as that of FAW Jiefang's J6M. Xichai CA4180P1K2E6A80 is the
main engine below 350 horsepower, and Weichai CA4253P1K2T1E6A80 is
the main engine above 350 horsepower. There is also an LNG version,
which is also Weichai's natural engine.
Chassis configuration
The 9-speed and 12-speed transmissions are still domestic Fast, and
the 10-speed box is FAW's own CA10TA series. The tonnage of the
drive axle is smaller than that of the Tian V, mainly 435 and 457
axles, which provide 6×4 and 4×2 drive forms.
| Basic Information |
| Announcement model: | CA4253P1K2T1E6A80 | Drive form: | 6X4 |
| Wheelbase: | 3300+1350mm | engine: | Xichai CA6DM2-46E65 |
| Gearbox: | FAW Jiefang CA12TAX210M3 | Rear axle ratio: | 3.7 |
| Body length: | 6.88 meters | Body width: | 2.55 meters |
| Body height: | 3.34 meters | Front track: | 2020mm |
| Rear Track: | 1847/1847mm | Vehicle weight: | 7.6 tons |
| Total mass: | 25 tons | Total Traction Mass: | 40 tons |
| Maximum speed: | 102km/h | Origin: | Changchun/Qingdao/Chengdu |
| Tonnage class: | Heavy Truck | Remark: | Four-directional imagery, tire burst emergency, lane departure
warning, steering assist lights |
| Engine parameters |
| engine model: | Xichai CA6DM2-46E65 | Engine Brand: | Xichai |
| Number of cylinders: | 6 | Fuel type: | diesel fuel |
| Cylinder arrangement: | In-line | Displacement: | 11.05L |
| Emission Standards: | country six | Maximum horsepower: | 460 hp |
| Maximum output power: | 341kW | | |
| Cab parameters |
| Cab: | high roof | Number of passengers allowed: | 3 people |
| Transmission parameters |
| Gearbox Model: | FAW Jiefang CA12TAX210M3 | Gearbox brand: | FAW Jiefang |
| Shift method: | manual | Forward gear: | 12 gears |
| Number of reverse gears: | 2 | | |
| Chassis parameters |
| Frame size: | 300×80×8mm | Front axle description: | DY011 Front axle |
| Description of rear axle: | 435 punch welding bridge | Front axle allowable load: | 7000kg |
| Rear axle allowable load: | 18000 (two-axis group) kg | Speed ratio: | 3.7 |
| Number of spring pieces: | 2/3 | Saddle: | Ф50 |
| tire |
| Number of tires: | 10 | Tire specifications: | 12R22.5 |
| control configuration |
| ABS Anti-lock Braking: | ● | EBS electronic braking system: | ● |
| Internal configuration |
| Multifunction steering wheel: | ● | | |
| Smart configuration |
| Tire pressure monitoring system: | ● | | |
