Foton Auman GTL 470HP 4X2 AMT Automatic Transmission Tractor
(Country VI)(BJ4189Y6ADL-01)
Foton Truck, 4*2 Truck, Tractor Head Truck, 4*2 Tractor Head
For express e-commerce vehicles that have been under high-intensity
operation for a long time, it is common for people to park without
stopping. Under such a high-load state, the reliability of the
engine is extremely important. This Auman GTL is equipped with a
Fukang A12 engine with a maximum output of 470 horsepower and a
peak torque of 2300 Nm in the 1000-1400 rpm range.
From the perspective of power parameters, 470 horsepower is very
suitable for express standard transportation. It is just right for
4x2 tractors, and it is also conducive to fuel economy. The
reliability and durability of Fukang engines are also well-known in
the industry. More tolerant to various working conditions.
The gearbox part is matched with a ZF Chuansheng 12-speed AMT
gearbox. The shifting mechanism adopts an integrated design, which
has a higher integration rate and a lower failure rate. The Fukang
and ZF AMT power chain must be familiar to everyone. It is very
mature in the market. After integrated matching, it has been well
compatible in performance, fuel consumption, ride comfort and other
aspects. For the high-efficiency and high-attendance transportation
scene of express e-commerce, this set of power is an ideal choice.
The chassis of the car looks particularly short, with 295/60R22.5
tires. We also compared another Auman GTL chassis with 12R22.5
tires next to it, and the entire chassis height will be
significantly different. In addition, this car also has an airbag
rear axle, which can adjust the height of the airbag through an
electronic control system, which can further lower the chassis. The
chassis height is relatively lower, the height of the cargo bed can
be made higher, and the volume is relatively more advantageous.
| Basic Information |
| Announcement model: | BJ4189Y6ADL-01 | Drive form: | 4X2 |
| Wheelbase: | 4200mm | engine: | Foton Cummins X12NS6B470 |
| Gearbox: | ZF 12TX2421TD | Rear axle ratio: | 2.714 |
| Body length: | 6.665 meters | Body width: | 2.55 meters |
| Body height: | 3.95 meters | Front track: | 2020mm |
| Rear Track: | 1860mm | Vehicle weight: | 7.1 tons |
| Total mass: | 18 tons | Total Traction Mass: | 34.77 tons |
| Maximum speed: | 110km/h | Market segments: | express express |
| Origin: | Huairou, Beijing | Tonnage class: | Heavy Truck |
| Engine parameters |
| engine model: | Foton Cummins X12NS6B470 | Engine Brand: | Foton Cummins |
| Number of cylinders: | 6 | Fuel type: | diesel fuel |
| Cylinder arrangement: | In-line | Displacement: | 11.8L |
| Emission Standards: | country six | Maximum horsepower: | 470 hp |
| Maximum output power: | 346kW | Max torque: | 2300N m |
| Maximum torque speed: | 1000-1400rpm | Rated speed: | 1900rpm |
| Cab parameters |
| Cab: | High ceiling standard floor | Number of passengers allowed: | 2 people |
| Seat row: | half row | | |
| Transmission parameters |
| Gearbox Model: | ZF 12TX2421TD | Gearbox brand: | ZF |
| Shift method: | AMT Manual | Forward gear: | 12 gears |
| Number of reverse gears: | 2 | Shell material: | Aluminum alloy |
| tank | | | |
| Fuel Tank/Gas Tank Material: | Aluminum alloy | Fuel tank capacity: | 1230L |
| Chassis parameters |
| Front axle allowable load: | 6500kg | Rear axle allowable load: | 11500kg |
| Speed ratio: | 2.714 | Number of spring pieces: | 2/- |
| tire |
| Number of tires: | 6 | Tire specifications: | 295/80R22.5 |
| control configuration |
| ABS Anti-lock Braking: | ● | |
|
